Rigid
Flex/Flex-Rigid
Layer Count
Finished Board Thickness
Max. Production Panel Size
Min. Line Width/ Line Space
Min. Hole Size
Mechanical
Laser
Max. Aspect/ratio
Laminate
Main Brands:
Shengyi, KB, Ventec, Nanya, ITEQ
Solder Mask Color
Main brands:
Tamura, Taiyo, OTC, Huntsman
Surface Finish
Profiling
Lead Time
Special Technology
• 1 - 58 layer
• 0.4 - 3.2 mm
• > 3.2 mm on request
• 450 mm x 600 mm
• 0.01/0.01mm for base copper Hoz and final Cu thickness 0.053mm
• 0.25 mm
• 0.1 mm
• 8:1
• CEM-1
• CEM-3
• FR-4
• Anti CAF
• Halogen free (RoHS compliance)
• BT epoxy
• PTFE Ceramic
• Rogers
• Green (shiny / semi-matte / matte)
• Blue
• Black
• White
• Red
• HAL Sn100CL (leadfree)
• Chemical Nickel Gold
• Electro Nickel Gold
• Chemical Tin
• Chemical Silver
• OSP
• Carbon print
• Peelable solder mask
• Resin plugging
• Routing
• Punching
• V-scoring / Jump V-scoring
• Express service: 15 days (FCA HK)
• Mass Production: 4 - 6 weeks (FCA HK)
• HDI boards (micro vias, buried vias)
• Press fit holes
Layer Count
Max Production Panel
Laminate
Shengyi / Ventec
Finished Board Thickness
Base Copper Thickness
Min. Finished Hole Size
Min. Line Width / Spacing
Profiling
LPI Solder Mask Color
Surface Finish
• 1 – 8 Layers
• 457mm x 610mm
• CEM-1
• CEM-3
• FR-4
• FR4 TG 170
• CTI600
• Anti CAF
• 0.4mm – 3.2mm
• 18 – 105µm
• 0.2mm finished (mechanical drilling)
• 0.1 / 0.1 mm
• Routing, Depth routing
• Punching
• V-scoring / Jump V-scoring
• Green (shiny / semi-matte / matte)
• Blue
• Black
• White
• Red
• HAL Sn100CL (lead-free)
• Chemical Nickel / Gold (max. gold
thickness = 0.1 µm)
• Electro Nickel / Gold (max. gold thickness of Gold Finger = 1.5 µm)
• Chemical Tin
• Chemical Silver
• OSP
• Carbon print
• Peelable mask
• Resin plugging (max. hole size = 0.5mm)
Layer Count
Finished Board Thickness
Max. Production Panel Size
Laminate
Main Brands:
PI = APlus, Taiflex, Thinflex
FR4 = Shengyi
Coverlay = APlus, Taiflex
Solder Mask Color
Main Brands:
Taiyo (UL approved)
Surface Finish
Profiling
Lead Time
Stiffener
• Rigid-Flex 10 Layer, Flex 8 Layer
• Rigid-Flex: 0.2 – 3.2 mm
• Flex: 0.15 – 1.0 mm
• 250mm x 1000mm (2L)
• 250mm x 500 mm (ML)
• FR-4
• Halogen free
• PI CCL material
• PET CCL material
• Coverlay
• PI-CCL on Aluminum
• Green
• Yellow
• Amber
• Blue
• Black
• White
• HAL
• HAL LF
• ENIG
• Electro Nickel Gold
• Chemical Tin
• Tin Plating
• Gold Finger
• Chemical Silver
• OSP
• Carbon Ink Print
• Punching
• Laser Cutting
• Routing
• Express service: 4 days (FCA HK)
• Mass Production: 4 - 5 weeks (FCA HK)
• PSA (pressure sensitive adhesive)
• TSA (thermal sensitive adhesive)
• Materials: FR4, Al, PI
